> 제품품목 > 밸브 VALVE

VALVE
품질과 납기를 최우선으로 하는 고객에게 신뢰받는 기업이 되겠습니다.

PDF 다운로드

Gate Valves

Rubber Seat Butterfly Valves (Concentric Design)

Serves as efficient stop valves with flow in either direction. They are commonly used where a minimum of pressure drop is important because they offer practically no resistance to flow when fully open. Throttling is not conducive to accurate and consistent flow control. Also the valves may be damaged by the high velocity across the seats. They function best fully open or fully closed.

PDF 다운로드

GLOBE VALVE

DESCRIPTION

serves as efficient stop valve with flow in either direction. They are commonly used where a minimum of pressure drop is important because they offer practically no resistance to flow when fully open. Throttling is not conducive to accurate and consistent flow control. Also the valve may be damaged by the high velocity across the seats. They function best fully open or fully closed.

CLASS

API 800, 1500
ANSI 150, 300, 600, 900, 2500, 4500

SIZE

3/8", 1/2", 3/4", 1", 11/4", 11/2", 2"

MATERIAL

ASTM A105, A182-F5, A182-F9, A182-F11, A182-F22, A182-F304, A182-F316, A182-F304L, A182-F316L, A182-F321, A182-F347, A182-F51, A182-F91, A350-LF2
Other Materials also Available on Application

END CONNECTION

Socket welding, threaded Butt welding, flanged

FEATURE

Bolted bonnet or welded bonnet
Outside screw & yoke
Plug disc
Integral seat

PDF 다운로드

CHECK VALVE

LIFT CHECK VALVE DESCRIPTION

They have an advantage over most other types of check valve in that they need only a relatively short lift to obtain full valve opening. The lift check valve uses a free-moving closure element that is placed above the seat. It prevents backflow and maintains pressure. The lift check valve is recommended to install in horizontal piping lines because the disc is pushed up by the flow until the flow reverses when gravity and down stream pressure close the closure element against the seat.

CLASS

API 800, 1500
ANSI 150, 300, 600, 900, 1500, 2500, 4500

SIZE

3/8", 1/2", 3/4", 1", 11/4", 11/2", 2"

MATERIAL

ASTM A105, A182-F5, A182-F9, A182-F11, A182-F22, A182-F304, A182-F316, A182-F304L, A182-F316L, A350-LF2

END CONNECTION

SOCKET WELDING, THREADED
BUTT WELDING, FLANGED

FEATURE

BOLTED COVER OR WELDED COVER
INTEGRAL SEAT

SWING CHECK VALVE DESCRIPTION

prevent reversal of flow through pipe lines. The swing check valve uses a hinged door to open during flow and to close against a pressure reversal. Swing check valve can be installed in horizontal or vertical upward flow piping. They offer low resistance to flow and are particularly suited to low velocity service

CLASS

API 800, 1500
ANSI 150, 300, 600, 900, 1500

SIZE

3/8", 1/2", 3/4", 1", 11/4", 11/2", 2"

MATERIAL

ASTM A105, A182-F5, A182-F9, A182-F11, A182-F22, A182-F304, A182-F316, A182-F304L, A182-F316L, A182-F321, A182-F347, A182-F51, A182-F91, A350-LF2
Other Materials also Available on Application

END CONNECTION

SOCKET WELDING, THREADED
BUTT WELDING, FLANGED

FEATURE

Bolted cover or welded cover
Renewable seat
